Service & Application
•Compact, robust, economical one piece design
•Low operation torque
•Blow out proof stem
•Lockable lever handle operation with insulated grip
•PTFE seals
•Reduced bore
•Screwed BSP ends (NPT ends available on request)
•Designed and manufactured according to ASME B16.34
•Inspected and tested accoridng to API 598
•Screwed connections according to ANSI B1.20.1
04/0038
Mars Stainless Steel 1 Piece Reduced Bore Ball Valve, Class 800, Lockable Lever
1 kg
Price range: £8.96 through £52.73
Note: Prices above are excluding VAT.
For delivery times and further info please call our team 01942 885700 or email us.
Other sizes or types may be available upon request. We can source special items to your requirements – please contact us for details
Speak to one of our valve experts today!
| Specification | Details |
|---|---|
| Operation | Hand Lever |
| Connections | ANSI B1.20.1 |
| Test & Inspection | API 598 |
| Maximum Pressure | 1000 PSI |
| Body | CF8M |
| Seat | PTFE |
| Gasket | 316 SS |
