VIP PN6 Flanged Tied EPDM Rubber Flexible Connectors
Key Information
VIP PN6 Tied EPDM Rubber Flexible Connectors are designed to absorb vibration, reduce noise transmission, and accommodate movement in low-pressure pipework systems while providing added stability through integrated tie rods. Manufactured from durable EPDM rubber with reinforced nylon construction and galvanised steel flanges, these connectors are ideal for water, warm water, sea water, air, and weak acid applications. The tied design helps control axial movement and limit overextension under pressure, making them particularly suitable for pumps, HVAC systems, and industrial installations where additional restraint and pipeline protection are required.
*Please note: VIP Rubber Pump Flexibles should not be used at both their maximum working temperature and pressure simultaneously.
| VIP Code | Nominal Pipe Size | Neutral Length | Axial Compression | Axial Elongation | Lateral Deflection | Angular Deflection |
|---|---|---|---|---|---|---|
| mm | mm | mm | mm | (+/- mm) | (+/- Degrees) | |
| 00/0596/040 | 40 | 130 | 12 | 10 | 12 | 15 |
| 00/0596/050 | 50 | 130 | 12 | 10 | 12 | 15 |
| 00/0596/065 | 65 | 130 | 12 | 10 | 12 | 15 |
| 00/0596/080 | 80 | 130 | 12 | 10 | 12 | 15 |
| 00/0596/100 | 100 | 130 | 12 | 10 | 12 | 15 |
00/0596 Datasheet (PN6 Flanged Tied EPDM Rubber Flexible Connectors)
Download
